Lectrosonics DSR4SUPER Unislot Camera Adapter Kit for DSR4 Receivers

The Lectrosonics DSR4SUPER is a Unislot camera adapter kit that mounts a DSR4 receiver in SuperSlot docks and in camera slots such as those on Ikegami and Panasonic cameras.

The kit replaces the DSR4’s rear panel with a DB25 connector wired for power, audio, and data. The kit also has the blue mounting bezel and the screws that fit it to the receiver. Short screws attach the bezel to the receiver, and long screws from the other side lock the bezel in place.

Good to Know

The DSR4 draws nearly 700 mA at 7 VDC, more than many camera slots supply. Use it only in a camera slot rated by the camera’s maker for that current.

Features

• DB25 rear panel and bezel for the DSR4
• Fits SuperSlot docks and Unislot camera slots
• Wired for power, audio, and data

About Lectrosonics

Lectrosonics has built professional audio gear in New Mexico since 1971, today in Rio Rancho, and has kept its production in the United States. Its wireless IFB system, introduced in 1998, came into wide use in broadcast and film, and its Digital Hybrid Wireless line followed in 2002. Lectrosonics equipment carries a one-year factory warranty against defects in materials and workmanship, and its own factory service center handles repairs.
