PSC RF 4 Pack Slot Receiver Power and RF Distribution
- RF distribution and battery power for two slot receivers
- Takes two NP-1 or Smart batteries
- Single, Dual, or Wide Band versions
From $1,502.25 USD
PSC RF 4 Pack Slot Receiver Power and RF Distribution
The PSC RF 4 Pack carries two slot receivers and gives them RF distribution and battery power in one compact unit for a sound bag.
It is a smaller version of the PSC RF Six Pack, with active, filtered RF distribution, and having RF and battery distribution in one unit cuts weight, size, and cabling in a bag. Remote antenna power is built in, and two RF outputs daisy chain a second unit or feed RF to another device.
The power section takes two external NP-1 or Smart batteries, and a multicolor LED meter, set for the battery type in use, reads them. Audio comes out on mini XLR connectors and on a DB-15 multipin. With Wisycom receivers in AES mode, the RF 4 Pack carries up to eight channels of digital audio. It is made in the U.S.A. in Single Band, Dual Band, and Wide Band versions.
Features
- Holds two slot receivers
- Built-in RF distribution and filtering
- Remote antenna power
- Battery distribution for two external NP-1 or Smart batteries
- Multicolor LED battery meter
- Two RF outputs for daisy chaining
- Mini XLR and DB-15 audio outputs
- Made in the U.S.A.
Available Options
| Band | Frequency Range | Part Number |
|---|---|---|
| Single Band | 470 to 700 MHz | RF4PSB |
| Dual Band | 470 to 618 MHz and 940 to 960 MHz | RF4PDB |
| Wide Band | 470 to 960 MHz | RF4PWB |
Specifications
| RF | |
|---|---|
| Frequency Range | Single Band 470 to 700 MHz; Dual Band 470 to 618 MHz and 940 to 960 MHz; Wide Band 470 to 960 MHz |
| Inputs | BNC, 50 ohms |
| Outputs | SMA, 50 ohms |
| Maximum Input Signal | +13 dB |
| Noise Figure | 0.8 dB |
| General | |
| Power | 12 to 18 VDC, 170 mA |
| Batteries | 2 x external, NP-1 or Smart battery |
| Audio Outputs | Mini XLR and DB-15 multipin |
| Size | 9.25 × 5.75 × 1.6 in (23.5 × 14 × 4 cm) |
| Weight | 1.6 lb (0.725 kg) |
| Chassis | Aircraft aluminum, black wrinkle-texture powder coat |
| Warranty | 1 year, limited |
| Latest Specifications | Specifications are subject to change without prior notice. For current information, visit www.professionalsound.com. |
