Fostex 6301NE Active Monitor Speaker

299.99 USD

Fostex 6301NE — Confidence monitor 4-inch Pwrd Electrically balanced

In Stock

Quantity:

SKU: FOS.6301NE Categories: , Tag:
Share on:
Share on google Share on pinterest Share on mail

Description

Confidence monitor 4-inch Pwrd Electrically balanced

Model 6301-series have been on the market since 1982 as the standard active monitor speaker in the broadcast and production facilities and now we have re-design the speakers with the latest D-class power amplifier and new driver unit featuring energy saving “auto stand-by” function.

Key Features:

  • 20W D-class power amplifier for higher output level and less power consumption with no heat sink
  • Dedicated 4-inch full range driver for clear audio reproduction
  • Traditional rugged enclosure of aluminum die-cast with the physically identical height and width to the current B-series
  • Flat panel design to avoid inadvertent power-off or level change
  • Auto Stand-by mode (compliant to ErP directive) for energy saving
  • Detachable IEC type power inlet with multi-voltage power handling
  • Newly designed mounting bracket (EB-6301) for wall mounting with variable angle adjustments

Options:

EB-6301 U-Bracket-The optional rugged EB-6301 U-Bracket for the 6301B/6301N series speakers is available providing a range of mounting options.

Enclosure type: closed
Unit: 4” full range
Frequency response: 70 Hz – 15k Hz
Sound Pressure Level: 85dB / W (1m)
Maximum SPL: 98dB
AMPLIFIER SECTION
Inputs
All Models Connector: 1/4” TS Phone (unbalanced)
Input Impedance: 10k ohm or more
6301NX Connector: XLR-3-31 (transformer balanced)
6301NE Connector: XLR-3-31 (electrically balanced)
6301ND Connector: XLR-3-31 (IEC 60958 AES/EBU)
6301DT Connector: RJ45 (Dante)
Output (Thru)
6301ND Connector: XLR-3-32 (IEC 60958 AES/EBU)
Rated output: 20W
Distortion (T.H.D.): 0.05% (1kHz / 1W output)
Residual Noise:
  • -70dBV or less (NB/NE/NX). -65dBV (DT)
  • -65dBV or less (ND)
Input Sensitivity:
  • 1/4” TS phone: -14dBV (0.2Vr.m.s.)
  • XLR: +4dBu (1.2Vr.m.s.)
  • XLR(Digital): -12dBFS
Auto Stand-by: active after approx. 25 min. of continuous input lower than the threshold level
GENERAL
Dimensions: 120 (W) x 189 (H) x 120 (D) mm
Weight:
  • NB/NE/ND: 2.2kgs
  • NX/DT: 2.3kgs
Power Requirement: AC 100 – 240V (50/60Hz)
Power Consumption: 10W (less than 0.5W in stand-by mode)
