Shure ADX1M Axient Digital Micro Bodypack Transmitter (G57)
- Micro Axient Digital bodypack, 100 g with battery
- Internal antenna and sealed LEMO input
- Up to 7 hours on the SB910M battery
$3,059.00 USD
Shure ADX1M Axient Digital Micro Bodypack Transmitter (G57)
The Shure ADX1M packs Axient Digital transmission into a micro bodypack 68 mm wide and 18 mm thick, small enough to hide under a costume or a shirt.
An internal adaptive antenna keeps the signal steady when the pack sits against the body, so there is no whip antenna to route. Sealed buttons and a recessed LEMO input keep out sweat and moisture, and the housing is heat-resistant Ultem PEI plastic.
The SB910M rechargeable battery gives up to 7 hours of use, and ShowLink, Shure’s 2.4 GHz control link, lets the receiver adjust the pack remotely. This version covers the G57 band, 470 to 616 MHz.
Features
- Micro bodypack, 100 g with battery
- Internal adaptive antenna
- Sealed buttons and recessed LEMO input
- Heat-resistant Ultem PEI housing
- High-contrast OLED display
- ShowLink remote control
- 2, 10, or 20 mW RF power
- Up to 7 hours on an SB910M battery
- Detachable belt clip
What's Included
- SB910M rechargeable battery
- Belt clip
Specifications
| RF | |
|---|---|
| Frequency Band | G57: 470 – 616 MHz (gap from 608 to 614 MHz) |
| RF Power | 2, 10, or 20 mW, by region |
| Transmission Modes | Standard (350 kHz spacing) or High Density (125 kHz spacing) |
| Line-of-Sight Range | 100 m (300 ft) |
| Encryption | AES-256 |
| Antenna | Internal adaptive (integrated helical) |
| ShowLink | 2.40 – 2.4835 GHz, IEEE 802.15.4 |
| Audio | |
| Input | LEMO, 8.2 kΩ |
| Maximum Input Level | 8.5 dBV |
| Mic Offset | −12 to 21 dB in 1 dB steps |
| Frequency Response | 20 Hz – 20 kHz |
| Power and Physical | |
| Battery | SB910M rechargeable lithium-ion, up to 7 hours at 10 mW |
| Dimensions | 60.4 × 68 × 18 mm (2.38 × 2.68 × 0.71 in) H x W x D, without clip |
| Weight | 100 g (3.5 oz) with battery 68 g (2.4 oz) without battery |
| Housing | Plastic (Ultem PEI) |
| Operating Temperature | −18 to 50 °C (0 to 122 °F) |
| Latest Specifications | Specifications are subject to change without prior notice. For current information, visit www.shure.com. |
