Sennheiser EW-DP 835 Portable Digital Wireless Set
- Portable digital UHF kit with an MMD 835 handheld
- Camera-mounted EW-DP EK receiver
- Locking 3.5 mm and XLR camera cables
From $749.00 USD
Sennheiser EW-DP 835 Portable Digital Wireless Set
The Sennheiser EW-DP 835 is a portable digital UHF wireless kit for on-camera interviews, with an MMD 835 handheld and an EW-DP EK receiver that mounts on the camera.
The MMD 835 is a dynamic cardioid capsule on an EW-D SKM-S handheld, a good choice for isolating the voice when a street or event is noisy. Working in UHF rather than the crowded 2.4 GHz band gives more range and a steadier link. The 134 dB dynamic range handles quiet and loud voices without changing settings.
The cheese plate fits the camera by cold shoe or mounting screws, and magnets hold the receiver on the plate, so the receiver goes on in under a second. The receiver display shows the battery time left, and the locking cables in the box connect to a camera’s 3.5 mm or XLR input.
Frequency Bands
This page offers three US bands: Q1-6 (470.2 to 526 MHz), R1-6 (520 to 576 MHz), and R4-9 (552 to 607.8 MHz). Each covers up to 56 MHz.
Good to Know
EW-DP is fully digital and replaces the analog evolution wireless G4. It does not work with G3 or G4 transmitters or receivers.
Features
- MMD 835 dynamic cardioid capsule on an SKM-S handheld
- EW-DP EK camera receiver
- Digital UHF, 134 dB dynamic range, 1.9 ms latency
- Magnetic cheese plate mounting
- Battery time shown on the display
- Locking 3.5 mm and XLR camera cables
What's Included
- EW-DP EK portable single-channel receiver
- EW-D SKM-S handheld transmitter
- MMD 835 microphone capsule
- Mounting kit (cheese plate, cold shoe, belt clip, and screws)
- BA 70 rechargeable lithium-ion battery
- 2 x AA batteries
- Locking 3.5 mm TRS to 3.5 mm TRS cable
- Locking 3.5 mm TRS to XLR cable
- USB-C charging cable
- Quick guide
- Safety guide
Specifications
| System | |
|---|---|
| Frequency Ranges | Q1-6: 470.2 – 526 MHz R1-6: 520 – 576 MHz R4-9: 552 – 607.8 MHz |
| Audio Frequency Response | 20 Hz – 20 kHz (−3 dB) |
| Dynamic Range | 134 dB |
| Latency | 1.9 ms |
| Bluetooth Low Energy | 2402 – 2480 MHz |
| Operating Temperature | −10 to +55 °C (14 to 131 °F) |
| EW-DP EK Receiver | |
| Audio Output | < 2 dBV max. (high level) |
| Headphone Output | < 50 mW into 16 Ω |
| Power | BA 70 rechargeable pack, 2 AA batteries, or USB-C |
| Dimensions | 86 × 67 × 28 mm (3.39 × 2.64 × 1.1 in) |
| Weight | 140 g (4.94 oz) |
| EW-D SKM-S Handheld Transmitter | |
| Capsule | MMD 835, dynamic, cardioid |
| Sensitivity | 2.1 mV/Pa |
| Max. Sound Pressure Level | 154 dB SPL |
| Housing | Metal, with mute switch |
| Transmission Power | 10 mW ERP (audio link) |
| Power | 2 AA batteries (included), up to 8 hours BA 70 rechargeable pack (sold separately), up to 12 hours |
| Dimensions | Ø 50 × 268 mm (Ø 1.97 × 10.55 in) with MMD 835 |
| Weight | 304 g (10.72 oz) with MMD 835 |
| Warranty | 2 years |
| Latest Specifications | Specifications are subject to change without prior notice. For current information, visit www.sennheiser.com. |
