Neutrik NP3C 3-Pole 1/4-Inch Phone Plug
- 3-pole 1/4-inch phone plug
- Rugged diecast metal shell and chuck-type strain relief
- Black housing with gold contacts
From $11.43 USD
Neutrik NP3C 3-Pole 1/4-Inch Phone Plug
The Neutrik NP3C is a 3-pole 1/4-inch phone plug with a rugged diecast metal shell and a chuck-type strain relief for cable protection.
Its precision-machined one-piece contacts keep the tip contact from snagging. The brass contacts take wire up to 1 mm² (18 AWG) on solder terminations, and the strain relief holds cable from 4 to 7 mm in outer diameter.
It complies with IEC 60603-11 and EIA RS-453 and is rated for over 1,000 mating cycles. Trew Audio carries it with a black housing and gold contacts.
Features
- 3-pole 1/4-inch phone plug
- Rugged zinc diecast metal shell
- Chuck-type strain relief for cable from 4 to 7 mm
- Precision-machined one-piece contacts
- Solder terminations for wire up to 1 mm² (18 AWG)
- Rated for over 1,000 mating cycles
- Black housing with gold contacts
Specifications
| General | |
|---|---|
| Connection Type | Plug |
| Poles | 3 |
| Gender | Male |
| Electrical | |
| Contact Resistance | Depends on the mating connector |
| Dielectric Strength | 1 kV DC |
| Insulation Resistance | Over 2 GΩ (initial) |
| Rated Current per Contact | Depends on the mating connector |
| Rated Voltage | Under 50 V |
| Mechanical | |
| Cable O.D. | 4 – 7 mm 0.16 – 0.28 in |
| Lifetime | Over 1,000 mating cycles |
| Wire Size | 1 mm² (18 AWG) |
| Wiring | Solder contacts |
| Material | |
| Bushing | Polyacetal (POM) + PU |
| Contact Plating (Nickel Contacts) | 2 µm Ni (Su) |
| Contact Plating (Gold Contacts) | 0.2 µm Au |
| Contacts | Brass (CuZn39Pb3) |
| Insert | Polyamide (PA 6.6 30% GR) |
| Shell | Zinc diecast (ZnAl4Cu1) |
| Shell Plating (Nickel Housing) | Nickel |
| Shell Plating (Black Housing) | Black chromium |
| Strain Relief | Polyacetal (POM) |
| Environmental | |
| Standard Compliance | IEC 60603-11 / EIA RS-453 |
| Solderability | Complies with IEC 68-2-20 |
| Temperature Range | −20 to 65 °C −4 to 149 °F |
