Zoom M3 MicTrak Shotgun Mic Recorder
199.99 USD
In Stock
Zoom M3 MicTrak Shotgun Mic Recorder
The Zoom M3 MicTrak is a lightweight, stereo on-camera shotgun microphone/recorder that records in 32-bit float ensuring you capture perfect audio every take. The M3 features a line out to send audio directly to your camera’s input and has a selectable mono/stereo pickup pattern allowing you to control the precision and ambiance of your recording.
Specifications
| INPUTS | CHANNELS | 2(BUILT IN MS SHOTGUN MIC) | |
| MIC INPUT | MIC TYPE | Super-cardioid/bi-directional | |
| SENSITIVITY | MID MIC: -39 dB, 1 kHz at 1 Pa SIDE MIC: -39 dB, 1 kHz at 1 Pa |
||
| INPUT GAIN | Adjustment unnecessary (dual AD converter circuits used) |
||
| MAX SOUND PRESSURE INPUT | MID MIC: 132 dB SPL SIDE MIC: 122 dB SPL |
||
| OUTPUTS | LINE OUT | CONNECTOR | 1/8″ stereo mini jack |
| MAXIMUM OUTPUT LEVEL | +1 dBu | ||
| HEADPHONE | CONNECTOR | 1/8″ stereo mini jack | |
| MAXIMUM OUTPUT LEVEL | 20 mW +20 mW (32 Ω load) |
||
| RECORDING | RECORDING MEDIA | 4GB–32GB microSDHC cards 64GB–1TB microSDXC cards |
|
| WAV | SUPPORTED FORMATS | 48kHz 32-bit float stereo BWF |
|
| MAXIMUM SIMULTANEOUS RECORDING TRACKS |
4 (STEREO + MS RAW) | ||
| POWER SUPPLIES | BATTERIES | 2 AA | |
| AC ADAPTER | ZOOM AD-17 (DC 5 V/1 A) • USB bus power is supported. |
||
| USB | CONNECTOR | USB Type-C | |
| MASS STORAGE | CLASS | USB 2.0 High Speed | |
| AUDIO INTERFACE WITH REC |
CLASS | USB 2.0 High Speed | |
| SAMPLING RATE | 48kHz | ||
| BIT RATE | 24-bit integer | ||
| CHANNELS | 2 in/2 out | ||
| ESTIMATED CONTINUOUS OPERATION TIME USING BATTERIES | 48 kHz/32-bit float, 2ch recording to microSDHC card | Alkaline batteries: about 12 hours | |
| INCLUDED ITEMS | QUICK GUIDE | ||
| FORM WINDSCREEN | |||
| STEREO MINI CABLE | |||
| SHOCKMOUNT | |||
