Sony UTX-M40 Wireless Handheld Microphone (941 to 960 MHz)
- Dynamic capsule with a unidirectional pattern
- Interchangeable head for a wide choice of capsules
- NFC SYNC for quick, secure channel setting
$399.00 USD
Sony UTX-M40 Wireless Handheld Microphone (941 to 960 MHz)
With a dynamic, unidirectional capsule, the Sony UTX-M40 wireless handheld microphone favors the person talking into it over the room around them.
This one is the 90UC block, tuning 941.625 to 951.875 MHz, 953.000 to 956.125 MHz, and 956.625 to 959.625 MHz. The head is interchangeable, so other capsules fit in place of the supplied one, and the metal body runs on two AA batteries for about 8 hours at 30 mW. RF output switches between 30 mW and 5 mW.
Hold it next to a URX-P40 receiver and NFC SYNC sets the channel, while the URX-P03, URX-P03D, and URX-S03D receivers set it over IR. Auto gain mode looks after the input level, and a +15 dB boost lifts an off-mic voice.
Features
- Dynamic capsule with a unidirectional pattern
- Interchangeable head for a wide choice of capsules
- NFC SYNC for quick, secure channel setting
- Auto gain mode and a +15 dB boost for off-mic audio
- Sends its frequency to the receiver, for matching several receivers to one transmitter
- Works with the Sony WL-800, UWP, and UWP-D series
- OLED display that reads well indoors and outdoors
What's Included
- UTX-M40 handheld microphone
- Microphone holder
Specifications
| Carrier Frequencies | 90UC: 941.625 to 951.875 MHz, 953.000 to 956.125 MHz, and 956.625 to 959.625 MHz |
|---|---|
| Oscillator Type | Crystal-controlled PLL synthesizer |
| Antenna Type | 1/4 λ wavelength wire antenna |
| RF Output Power | 30 mW/5 mW selectable |
| Capsule Type | Dynamic |
| Directivity | Unidirectional |
| Reference Audio Input Level | −55 dBV (GAIN MODE set to NORMAL, 0 dB attenuation) |
| Maximum Audio Input Level | 151 dB SPL (21 dB attenuation, with the supplied microphone unit) |
| Audio Attenuator Range | 0 dB to 21 dB (3 dB steps) |
| Frequency Response | 70 Hz to 18 kHz (typical) |
| Signal-to-Noise Ratio | 60 dB (−60 dBV, 1 kHz sine wave); 102 dB (AUTO GAIN, max. deviation); 96 dB (NORMAL, max. deviation) |
| Distortion | 0.9% or less (−60 dBV, 1 kHz input) |
| Audio Delay | Approx. 0.35 ms |
| Display | OLED |
| Power Requirements | DC 3.0 V (2 AA alkaline batteries); DC 5.0 V (USB Type-C) |
| Battery Life | Approx. 8 hours at 30 mW |
| Operating Temperature | 0 °C to 50 °C (32 °F to 122 °F) |
| Dimensions | ø48 × 258 mm (1 15/16 × 10 1/4 in) |
| Weight | Approx. 255 g (9.0 oz), without batteries |
