Listen Technologies LR-4200-216 Intelligent DSP RF Receiver (216 MHz)

  • Personal receiver for 216 MHz ListenRF systems
  • Set to one channel for simple use
  • Rechargeable lithium-ion battery, 8 hours of use

$209.00 USD

Brand: Categories: , , Trew SKU: LIS.LR4200216 MPN: LR-4200-216

Listen Technologies LR-4200-216 Intelligent DSP RF Receiver (216 MHz)

The Listen Technologies LR-4200-216 is a compact personal receiver from Listen’s intelligent DSP (iDSP) line for 216 MHz ListenRF assistive listening. It is set to one channel, so a listener only turns it on and sets the volume.

The venue sets the channel, one of 57 (19 wide band and 38 narrow band), with the volume buttons or Listen’s free iDSP software over USB. The listener cannot change it. Programmable squelch mutes the audio when the signal is lost.

Two 3.5 mm outputs let two listeners share one receiver. A DSP loop driver serves listeners with T-coil hearing aids through Listen’s neck loop lanyard, sold separately. The receiver can be worn on the lanyard or on a belt clip. The earphone or lanyard cable serves as the antenna.

A non-proprietary, field-replaceable lithium-ion battery runs the receiver for 8 hours of continuous use. It charges over micro USB, and its extra contacts let it charge in other ways, such as in Listen’s 12-unit charging tray and carrying case. The OLED display shows the channel, battery level, unit number, and charging status.

Features

  • 57 channels on 216 MHz, set to one channel for the listener
  • Programmable squelch
  • Two 3.5 mm outputs for sharing
  • DSP loop driver for T-coil hearing aids
  • Field-replaceable lithium-ion battery, 8 hours of use
  • OLED display
  • Micro USB charging, setup, and firmware updates

What's Included

  • LR-4200-216 Intelligent DSP RF receiver
  • Field-replaceable lithium-ion battery
  • Quick start guide

Specifications

Frequency Range 216.0125 to 216.9875 MHz
Channels 57 (19 wide band, 38 narrow band)
Channel Selection One channel, set by the venue
Frequency Response 50 Hz to 15 kHz (±3 dB)
Signal-to-Noise Ratio 70 dB with SQ on, 50 dB with SQ off
Distortion Under 2% THD at 80% deviation
Sensitivity 0.6 µV typical, 1 µV maximum for 12 dB SINAD
Squelch Programmable in 20 steps, automatic on loss of RF signal
Audio Outputs Two 3.5 mm, unbalanced, 0 dBu nominal, 16 mW maximum, 32 ohms
Antenna Earphone or neck loop lanyard cable
User Controls Power, volume up and down
Programming iDSP software over USB
Display OLED: channel, battery level, unit number, charging status
Power Supply Micro USB, 5 V, 500 mA
Battery Lithium-ion, non-proprietary, field replaceable
Battery Life 8 hours of continuous use
Dimensions 3.75 × 2.0 × 0.64 in, H x W x D; 0.80 in deep with belt clip
Weight 1.6 oz (45.4 g); 2.4 oz (68.1 g) with battery
Operating Temperature 14 to 104°F (−10 to 40°C)
Compliance FCC Part 15, Part 90, Industry Canada, RoHS
