Deity UHF-TA THEOS Transmitter Antenna
- Transmitter antenna for the Deity THEOS DBTX
- Cut to length with the included chart
- Color-coded caps by band
$22.00 USD
Availability: In Stock
Deity UHF-TA THEOS Transmitter Antenna
The Deity UHF-TA is an antenna for the THEOS DBTX transmitter, cut to length for the frequency band in use.
Deity’s chart, included with each antenna, gives the cut length for seven bands between 550 and 928 MHz, from 116 mm for the lowest band down to 94 mm for the highest. A red, yellow, or blue cap marks the band the antenna is cut for, and the Specifications tab repeats the chart.
Features
- Cut to length for the band in use
- Cutting chart included
- Color-coded caps
- For the Deity THEOS DBTX transmitter
About Deity Microphones
Deity Microphones was launched by a TV location sound mixer, and their team works from a facility in Glendale, California. Their range covers THEOS digital wireless, field recorders, timecode gear, microphones, and power for sound bags and carts.
Specifications
| UHF-TA | |
|---|---|
| Frequency Range | 550 to 960 MHz |
| Length | Cut to the band in use |
| Cut Lengths (Deity’s chart) | |
| T1: 550 to 608 MHz | Red cap, 116 mm |
| T2: 614 to 616 and 653 to 663 MHz | Yellow cap, 111 mm |
| T3: 630 to 698 MHz | Yellow cap, 110 mm |
| T4: 733 to 758 MHz | Yellow cap, 102 mm |
| T5: 786 to 790 MHz | Blue cap, 98 mm |
| T6: 823 to 832 MHz | Blue cap, 97 mm |
| T7: 902 to 928 MHz | Blue cap, 94 mm |
